| Model Number : | CQH100 |
| Price : | 400USD/Piece |
| Delivery Time : | 3 days |
| Payment Terms : | TT |
| Supply Ability : | 500 pieces per month |
Applications:
Portable H2Detector is an intrinsically safe and explosion-proof instrument and is designed to deter H2.
Portable H2Detector is a low-cost, maintenance-free single gas monitor designed to protect personnel from dangerous H2gas exposure in the most extreme conditions. Despite its compact size, the single H2detector includes features usually found only in larger multi-gas monitors including a large, OLED display, internal audible/visual alarms and simple push-button operation.
The monitor continuously displays ambient combustible gas readings and will alert the user when gas concentrations exceed the preset low or high levels. Added features include adjustable alarm setpoints, calibration gas values, and choice of text-only display selected by the user through a simple, push-button routine. Single H2detector also has a peak/hold feature to show the highest reading during a shift and includes a special flip-cap calibration adapter for quick and simple calibration. Single H2detector is covered by a two-year warranty from the date of manufacture.
It is used at the underground coal mine and mine safety inspection mainly. Certainly, it is also applied to fire fighting, confined space, chemical industry, oil and all kinds of environment that needed to measure the combustible gas.
Feature | Benefit |
2-year warranty | Lowers the overall cost of ownership by providing a full 24 months of warranty coverage. |
Weight of 102g | Light weight and compact size, can be worn on the belt, shirt pocket, coveralls or hard-hat. |
Flip-cap calibration feature | Portable H2 Detector has a unique, built in calibration adapter to make calibration easy and eliminates the need to search for a calibration cup. |
OLED display | Provides continuous display of the actual concentration of combustible gas in the ambient environment as well as remaining battery life. |
Adjustable low and high alarm setpoints | The user can configure Portable H2Detector to suit a number of different applications. |
High visibility case | From a distance, it’s color makes it easy for Safety Professionals to verify that workers are protected. |
5 second delay shut-off protection | Portable H2Detector cannot be accidentally shut off since the on/off button must be depressed for five continuous seconds. |
Technical specification:
Sensors: | Electrochemical sensors (H2) |
Range: | H2:0~100ppm |
Accuracy: | 1ppm |
Resolution: | 1ppm |
Power Source: | 1500mAH lithium battery ；rechargeable battery |
TemperatureRange: | -4°F to 122°F (-20°C to 50°C) typical |
HumidityRange: | 0 to 95% RH typical |
Alarms: | Adjustable low and high alarm setpoints |
Explosion protection | Exibd I |
Protection grade | IP54 |
Dimensions: | 93mm×49mm×22mm |
Weight: | 102g |
Accessories:
battery, Carrying case and Operate guidebook
|
|
